GR Single Axle Gooseneck Stock 7000 lb. GVWR

• 12' to 18' L, 5' to 6.8' W, Capacity: 7,000 LB
• 2-5/16" Gooseneck Coupler (25,000 lb)
• Jack: 1) 10,000 lb Drop Leg Jack
• Top: Aero Nose & Half Metal Top
• Division Gate: 1 Solid Gate
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: One 7,000 lb Cambered Axle with electric brakes
• Suspension: Torsion
• Spare Tire &Wheel

• 16' L, 6'8" W, 6'6"T
• Dexter spring axles
• 2-5/16” adjustable gooseneck coupler
• Forward self-adjusting electric brakes on all wheels
• High brush style fenders
• Center gate with spring loaded hold back & slam latch with interior/exterior release
• Double swing in and out butterfly rear gates with a vertical and horizontal locking system

• 16' to 32' L, 6’8” W, 6’6” T
• 2-5/16” adjustable gooseneck coupler
• Dexter Spring Axles
• Spare tire and wheel
• Forward self-adjusting electric brakes on all wheels
• High brush style fenders
• Heavy duty anti climb with center gate with a spring loaded hold back and slam latch
• Heavy duty swing in and out butterfly rear gate with vertical and horizontal locking system

• 5' to 7' W, 14' to 28' L, Capacity: 14,000 LB
• 2-5/16" Gooseneck Coupler (25,000 lb)
• Jack: 1) 10,000 lb Drop Leg Jack (up to 24')
• Top: Choice of Bar top, Aero nose with tarp roof, Aero nose with full metal roof, Aero nose with partial metal roof
• Division Gate: 1 Solid Gate 14 ́ to 22 ́ Trailer / 2 Solid Gates 24 ́ to 28 ́ Trailers
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: Two 7,000 lb Cambered Axles with electric brakes
• Suspension: Torsion
• Spare Tire & Wheel

• 7' W, 20' to 28' L, Capacity: 16,000 LB
• 2-5/16" Gooseneck Coupler (25,000 lb)
• Jack: 2) 10,000 lb Drop Leg Jack
• Top: Choice of Bar top, Aero nose with tarp roof, Aero nose with full metal roof, Aero nose with partial metal roof
• Division Gate: 1 Solid Gate 20 ́ to 22 ́ Trailer / 2 Solid Gates 24 ́ to 28 ́ Trailers
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: Two 8,000 lb Cambered Axles with electric brakes (Dexter Axles)
• Suspension: Torsion
• Spare Tire & Wheel

• 7' W, 28' to 40' L, Capacity: 20,000 LB
• 2-5/16" Gooseneck Coupler (25,000 lb)
• Jack: 2) 10,000 lb Drop Leg Jack
• Top: Choice of Bar top, Aero nose with tarp roof, Aero nose with full metal roof, Aero nose with partial metal roof
• Division Gate: 3 Solid Gates 28 ́ to 40 ́ Trailer
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: Two 10,000 lb Cambered Axles with electric brakes (Dexter Axles)
• Suspension: Torsion
• Spare Tire & Wheel

• 6' to 7' W, 24' to 40' L, Capacity: 20,000 LB
• 2-5/16" Gooseneck Coupler (25,000 lb)
• Jack: 2) 10,000 lb Drop Leg Jack
• Top: Choice of Bar top, Aero nose with tarp roof, Aero nose with full metal roof, Aero nose with partial metal roof
• Division Gate: 2 Solid Gates on 24 ́ Trailers / 3 Solid Gates 28 ́ to 36 ́ Trailer / 4 Solid Gates on 40 ́ Trailers
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: Three 7,000 lb Cambered Axles with electric brakes
• Suspension: Torsion
• Spare Tire & Wheel

•  7' W, 24' to 44' L, Capacity: 4,000 LB
• 2-5/16" Gooseneck Coupler, (25,000 lb)
• Jack: 2) 10,000 lb Drop Leg Jack
• Top: Choice of Bar top, Aero nose with tarp roof, Aero nose with full metal roof, Aero nose with partial metal roof
• Division Gate: 2 Solid Gates on 24 ́ Trailers / 3 Solid Gates 28 ́ to 36 ́ Trailer / 4 Solid Gates on 40' to 44 ́ Trailers
• Rear Gate: Full Swing with Half Slider
• Escape Door: 36" Side Door (Left Side)
• Axles: Three 8,000 lb Cambered Axles with electric brakes (Dexter Axles)
• Suspension: Torsion

• 6’2” TALL
• Center gate 14’ & 16’
• Side access door
• Full swing half sliding rear gate
• Two chrome circle vents front

• 6’6” T, 6' or 6'8" W, 16' to 32' L
• Brush fenders full length
• Side access door above fenders
• Full swing half sliding rear gate on 6' wide
• Double swing in/out rear gate 6'8" wide
• Single center gate 16’ TO 20’
• Two center gates 24’ TO 28’
• Three center gates 32’
• Spare rack tire & wheel

• 6' to 7' W, 10' to 20'L
• Capacity: 7,000 LB
• Coupler: 2" Bulldog (7,000 lb)
• Drop Spring Axles

Options:

• Difference Between 2 Drop Spring Axles to 2 Torflex Axles
• Add Brakes To Second Axle
• Upgrade to 5,200 lb Drop Spring Axles
• Upgrade to 7,000 lb Drop Spring Axles
• Spare Tire & Wheel

• 14' or 16' L,  6’ or 6’8” W, 6’6” or 7’ T
• 2 5/16” forged coupler
• Forward, self-adjusting brakes all wheels
• Front slant tack room
• 3-place saddle rack
• Removable slant dividers w/ solid head partitions
• Dome lights

• All-aluminum construction
• 13' or 16'  L, 6'8" W, 7" T
• 2 5/16” forged coupler
• Forward, self-adjusting brakes on all wheels
• Front slant tack room
• Spare tire rack with spare tire & wheel
• Recessed dome lights
• Bridle hooks & brush trays
• Telescoping rear divider
• Adjustable, removable dividers w/ head partitions
• Roof vents, rubber floor mats & kick mats
• Drop feed doors on the road side, open stock sides on the curb side
• Removable 3-place saddle rack w/ blanket bars

• 17’ L, 6’8” W, 6’6” T
• 2 5/16” Bulldog coupler & safety chains
• 5200# Rubber torsion axles
• Forward self-adjusting electric brakes on all wheels
• Interior tie rings (1 per stall)
• One-piece rear door w/drop-leaf rear gate with slider
• Removable slant dividers with solid head partition

• 6’ L, 6’ W, 6’6” T
•  2-5/15” forged coupler
• 2-5200LB Rubber Torsion Axles
• Four-wheel independent suspension
• Greasable hubs
• Forward self-adjusting electric brakes on all wheels
• Emergency breakaway system
• Solid center gate
• Feed doors with recessed latches (2)
• Divider in front stall w/ solid head and shoulder petition
• Butt chains in front stall with cover
• Interior tie rings (2 in front, 2 at center gate)
• Exterior tie rings (2 per side)
• Full swing, half sliding rear gate
• 23” side access door curb side

• Slant load gooseneck horse trailer
• 13' to 20' L, 6’8” W, 6’6” T, up to 4 horses
• 2-5/16” adjustable gooseneck coupler
• Rubber torsion Dexter Axles
• Forward, self-adjusting brakes on all wheels
• Removable slant dividers w/ solid head partitions
• Front slant tack room
• 3-place saddle rack

• All-aluminum construction
• 15' to 21' L, 6’8” W, 7’ T, up to 4 horses
• Rubber torsion Dexter Axles
• 2-5/16” adjustable gooseneck coupler
• Spare tire & wheel
• Forward, self-adjusting brakes on all wheels
• Front slant tack with spare tire rack
• Recessed dome light
• Bridle hooks & brush trays
• Telescoping rear dividers
• Adjustable, removable slant dividers with head partitions
• Roof vents & dome lights
• Rubber floor mats & kick mats
• Drop feed doors road side, radius sliding windows curb side.
• Removable 3-place saddle rack w/ blanket bars

• 14’ to 16’ L, 5’ to 6’8” W, 6’6” T
• 2” forged coupler
• Dexter Spring Axles
• Forward self-adjusting electric brakes on all wheels
• Weights: 1960lbs, 2110lbs, 2740lbs, and 3010lbs
• Interior tie rings (2 in front, 2 at center gate)
• Center gate w/ spring loaded hold back & slam latch
• Full swing, half sliding rear gate
• 23” side access door curb side

• All-aluminum construction
• 16' L, 6'8" W, 7' T
• 2-5/16” forged coupler
• Rubber torsion Dexter Axles
• Spare tires & wheel
• Forward self-adjusting electric brakes on all wheels
• V-Nose, full height double lined internal front sheet
• Interior tie rings (2 in front, 2 at center gate)
• Center gate w/ spring loaded hold back & slam latch
• Full swing, half sliding rear gate
• 30” side access door curb side

• 16' L, 6'8" W, 6' T
• 2″ Bulldog coupler & safety chains w/ hooks
• Rubber torsion axles w/ four-wheel independent suspension & greasable hubs
• Silver modular wheels with chrome center caps
• Forward, self-adjusting electric brakes on all wheels
• Front straight tack & spare tire rack
• Full height straight partition wall between stock & front tack room
• 30″ full tack door, recessed locking handle & hold back (located on curb side of nose)
• Priefert Exclusive 6 Pen gate system (removable)
• 6 adjustable, two-way flip up roof vents
• Framed for A/C (no cutout)
• 50/50 solid rear doors w/ cam latches
• Window in each rear door
• Fold-Down half ramp w/spring assist (mounted behind rear doors).

• 16', 20', 24' L, 6’8” W, 6’6” T
• Drop down calf gate in front
• Interior tie rings (2 in front, 2 at center gate)
• Center gate w/ spring loaded hold back & slam latch (24’ has 2)
• 2-5/16” adjustable gooseneck coupler
• Dexter spring axles
• Forward self-adjusting electric brakes on all wheels
• Spare tire and wheel
• Full swing, half sliding rear gate
• 30” side access door curb side

• All-aluminum construction
• 16' to 28' L, 6’8” W, 6’6” to 7’ T
• Rubber torsion Dexter axles
• 2-5/16” adjustable gooseneck coupler
• Spare tire & wheel
• Forward, self-adjusting brakes on all wheels.
• Drop down calf gate at the front
• Interior tie rings (2 in front, 2 at center gate)
• Center gate w/ spring loaded hold back & slam latch (24’ and 28’ have 2)
• Full swing, half sliding rear gate
• 30” side access door curb side

• 16' to 32' L, 6'8" W, 6'6" T
• 2-5/16” adjustable gooseneck couple
• Dexter spring axles
• Forward self-adjusting electric brakes
• Spare tire and wheel
• High brush style fenders
• 24" side access door curb side
• Heavy-duty anti-climb with center gate and spring loaded hold back and slam latch (24 ft. & 28 ft. have 2; 32 ft. has 3)
• Heavy duty double swing in and out butterfly rear gates
